DS-7616NI-I2/16P
DS-7616NI-I2/16P
This Hikvision DS-7616NI-I2-16P is a 16CH Plug and Play Network Video Recorder.
- Third-party network cameras supported
- Up to 12 Megapixels resolution recording
- Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K (3840×2160) resolution
- 8/16-ch network cameras can be connected with
- 80M/160M incoming bandwidth
- Up to 2 SATA interfaces
- Plug & Play with up to 16 independent PoE network interfaces
- Support dual-os to ensure high reliablility of system running
- Support various VCA detection alarm and VCA search
- Support H.265/H.264/MPEG4 video formats
£417.45
FREE SHIPPING
All over Gibraltar
FREE COLLECTION AT SMARTHOME
In a few minutes
SECURE PAY
By credit card
| Cameras | |
| Product Description | 16CH NVR |
| Specifications | |
| Alarm Input/Output | Alarm in/out 4/1 |
| Alarm Input/Output | Alarm In: 4-ch Alarm Out: 1-ch |
| Audio Channels | 1-ch, RCA (Linear, 1kΩ) |
| Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
| Dimensions | 380 × 290 × 45mm (15.0" × 11.4" × 1.8") |
| HDMI/VGA Output | Yes |
| Incoming Bandwidth | 160Mbps |
| IP Video Input | 8-ch (Up to 12 MP resolution & 4-ch@8MP,16-ch@1080P) |
| Monitor Outputs | HDMI & VGA |
| Network Interface | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| Operating Conditions | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| PoE Switch (Built In) | (-16P) 16xPort PoE |
| Power Consumption | ≤15 W (without enabling PoE & without HDD) |
| Power over Ethernet | (-16P) 16x PoE Ports |
| Power Supply | 12 VDC |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Resolution | HDMI: 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz VGA: 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Storage | Max 12TB 2 SATA interface for 2 HDD |
| Two-way Audio Input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Weight | ≤ 1 Kg (without HDD) |
